Multi-angle Gallery
Dimensions
| Length (mm) | 2,005 |
| Width (mm) | 865 |
| Height (mm) | 1,120 |
| Wheelbase (mm) | 1,370 |
| Dry Weight (kg) / without fuel and accesories | 128 |
| Ground Clearance (mm) | 215 |
| Fuel Tank Volume (L) | 12.5 |
| Seat Height From Ground (mm) | 800 |
Power System
| Number of Cylinders | Single Cylinder |
| Camshaft System | Single Overhead Camshaft/ 4 Valve |
| Bore * Stroke (mm) | 58 * 58.7 |
| Cooling System | Water Cooled |
| Fuel | Petrol |
| Compression Ratio | 12.5:1 |
| Displacement(cc) | 150 |
| Maximum Power (PS/ rpm) | 18 / 9,250 |
| Maximum Torque (Nm/ rpm) | 16 / 7500 |
| Fuel Supply System | Injection |
| Injection System | Bosch EFI |
| Transmission System | Drive Chain/ 6 Speed |
| Clutch Type | Multi-disc in oil bath |
Specifications
| Tyre construction | Dual-purpose tyre |
| Rim Type | DOT Rated tubeless cross-spoke rim |
| Front Tyre Size | 110/ 70-17 |
| Rear Type Size | 130/ 70-17 |
| Font Brake System | 300mm Disc Brake |
| Rear Brake System | 230mm Disc Brake |
| Lights/ Rear Lights/ Indicators | LED |
| ABS System | Dual channel ABS (Bosch) |
| Emission standards | Euro 5-BS6 |
ZT150-U1
An outstanding adventure-sport styled 150cc motorcycle, A perfect blend of style, performance and technology.
Anti-theft PKE (Passive Keyless Entry) System
The car-inspired PKE system consists of an attractively designed key fob, backed by robust engineering to ensure a high level of safety for your ZONTES. Just wear your ZONTES key by placing it in a wrist strap. With the key within 1.5 metres proximity, your bike gets unlocked; go far away – the bike gets locked automatically. Adopting advanced encryption technology, now your bike is impossible to be stolen !
Electronic Control | Premium back-lit switchgear
The auxiliary handle switches provides for electronic functionality. Tasks like unlocking your fuel tank or seat, with just a click of the button.
Aluminium alloy based components
Whether it is the handle lever or the muffler cover; side stand or the foot bracket, all are aluminium alloy. No cost-cutting even in the nooks and corners. Quality doesn’t require any justification for ZONTES. The use of aluminium alloy based components speak premiumness for itself !
Muscular fuel tank with galvanised liner
The tank has been designed aiming for muscular knee recesses for optimum rider triangle. Pressed from galvanized (zinc-coated) steel, now eliminate the clogging of fuel pump filter and the leakage of fuel tank due to rust. Pressed from galvanised steel, tank rust is a thing of the past.
BOSCH Dual - channel ABS
Enjoy safest braking and zero wheel locking scenario with your bike ! Uncompromised safety compared to a single-channel unit. Whether it is sandy or wet roads or gravel, BOSCH9.1M Dual – channel ABS has got you covered.
Largest-in-the segment Battery
Superbike grade large capacity 10AH battery provides sufficient punch for every energy-consuming task – be it chilly winter start-up or powering your USB charging ports. Low temperature performance of this battery is a benchmark in itself, allowing for feather-touch cranking !
Lightweight Alloy Tubeless Rims
Lightweight rims with side pull spokes ensures good impact resistance and enables use of tubeless tyres. And they look stunning…
Large Diameter Brake Discs
300mm front brake discs provide huge stopping power and a linear feeling under braking.
LED Lighting
Automotive grade LED lights projected from an aluminium die-cast shell, produces outstanding illumination field of vision. The lamp unit is designed to dissipate heat to prolong LED life and reduce luminaire decay.
Centre Mount Mono Shock
A centrally mounted mono shock softens the ride whilst delivering excellent control. Filled with high pressure nitrogen to ensure stability over long journeys and set with a small amount of pre-load, the rear suspension offers excellent comfort with reduced rider fatigue.
All Terrain Tyres
Complimenting the adventure motard styling are 110 mm (F) and 130mm (R) dual purpose tyres, which are the segment-widest adventure category tyres. These tyres not only perform great on tarmac but also in off-road and slippery conditions. Alongside increased straight-line stability, it also contributes to an enhanced adventure motard styling, specially from the rear.
Automotive grade stainless steel exhaust
Coupled with ‘cool-touch’ aluminium anti-hot plate, the (underbelly/stubby) stainless steel exhaust adheres the mass centralization approach. The automotive grade unit is corrosion resistance and ensures long service life. The exquisite design of the exhaust system also allows beautiful sound beat that is music to the ears.
Ergonomic Seat
Utilising the latest memory foam technology, the seat cushion offers comfort, even for the heavier riders. Ergonomic shaping gives excellent support to reduce fatigue, even on the longest of rides. Split seats allows for pillion removal and luggage box fitment.
Dual USB Port
The USB port supports faster charging with water – resistant, flame resistant and shock resistant structural design for a stress-free long ride. Just in case your smartphone runs out of juice, ZONTES has got you covered !
Pure Aluminium Alloy Rear Swingarm
Made in-house from independent casting, the pure aluminium alloy rear swingarm is not only rustproof but also aids significant reduction in un-sprung weight. This adds to the racing dynamics of the bike.
Intelligent Digital LCD Display
A fast response intelligent digital display presents the rider with all the essential information in a clear, concise arrangement.
Fully-loaded with accessories
The bike comes factory fitted with multiple accessories including knuckle guards, lever adjuster, inner mud-guards, crash guards etc.
Handguards
Solid bar ends with integrated forged lever guards are fitted with brush guards as standard.
Liquid cooled 4V engine
Running a high compression ratio of 12.5:1, the engine delivers power of 19.03PS @9250rpm and torque of 16NM 7500rpm. This makes it the most powerful 150cc engine in Nepal. Another important feature of a high compression engine is low fuel consumption, an increasingly relevant feature in today’s world. To achieve this Zontes utilises the latest materials and technologies available to design a class beating engine.
Large Radiator
Outstanding dissipation of heat from the cooling system enhances power and prolongs vehicle lifespan.
Assist & Slipper Clutch
The race-inspired clutch uses two types of cams (an assist cam and a slipper cam), offering two functions. Along with lighter clutch lever pull, assist cam also enables the clutch torque capacity to be increased without gaining weight. When excessive engine braking occurs – as a result of quick downshifts (or an accidental downshift) – the slipper cam comes into play, forcing the clutch hub and operating plate apart. This relieves pressure on the clutch plates to reduce back-torque and help prevent the rear tyre from hopping and skidding.
